How to install the CNC lathe (automated lathe machine tool)?
Lifting and transportation:
The lifting and positioning of the machine tool should use the special lifting tools provided by the manufacturer, and other methods are not allowed. No special lifting tools are needed, and steel wire ropes should be used to lift and place them in place according to the instructions.
Foundation and location:
The machine tool should be installed on a firm foundation, and the location should be far away from the source of vibration; avoid sunlight and heat radiation; be placed in a dry place to avoid the influence of humidity and airflow. If there is a vibration source near the machine tool, an anti-vibration trench must be set around the foundation.
Machine tool installation:
The machine tool is placed on the foundation, it should be leveled in a free state, and then the anchor bolts are evenly locked. For ordinary machine tools, the level meter reading does not exceed 0.04/1000mm, and for high-precision machine tools, the level meter does not exceed 0.02/1000mm. When measuring the installation accuracy, it should be carried out at a constant temperature, and the measuring tool should be used after a fixed temperature period. When installing the machine tool, every effort should be made to avoid forced deformation of the machine tool. Some parts of the machine tool should not be disassembled casually when the machine tool is installed. The disassembly of the parts may cause the redistribution of the internal stress of the machine tool, thereby affecting the accuracy of the machine tool.
Preparation before commissioning:
After the geometric accuracy of the machine tool is qualified, the whole machine needs to be cleaned. Use cotton or silk cloth soaked with cleaning agent, not cotton yarn or gauze. Clean the anti-rust oil or anti-rust paint applied to protect the guide rail surface and the machined surface when the machine tool leaves the factory. Clean the dust on the outer surface of the machine tool. Coat each sliding surface and working surface with lubricating oil specified by the machine tool.
Check carefully whether all parts of the machine tool are filled with oil as required, and whether enough coolant is added to the cooling box. Whether the oil of the hydraulic station of the machine tool and the lubrication device of the automatic room reaches the position specified by the oil level indicator.
Check whether the switches and components in the electrical control box are normal, and whether the integrated circuit boards are in place.
The centralized lubrication device is started by electrifying, so that the lubricating parts and the lubricating oil circuit are filled with lubricating oil. Make all the preparations before each part of the machine tool moves.
