 How to judge the correctness of the tool path of a vertical machining center?

1. Introduction of Vertical Machining Center

It refers to the machining center with the spindle axis and the worktable perpendicular to it. The main vertical machining center should be suitable for processing complex parts such as plates, plates, molds and small shells. The vertical machining center can complete processes such as milling, boring, drilling, tapping and cutting threads. The vertical machining center is at least three-axis and two-linkage, and generally can achieve three-axis and three-linkage.

2. The correctness of the tool trajectory of the vertical machining center

The vertical machining center can simulate the tool to move along the trajectory through trajectory simulation, reproduce the dynamic image display process of the blank cutting, and simulate the actual cutting process and results to judge the correctness of the tool trajectory. This simulation process is realized through the trajectory simulator. After the user picks up the relevant trajectory through the trajectory simulation command and confirms with the right mouse button, the trajectory simulator can be loaded for simulation. Here are two types of trajectory simulators. the way.

First click the track simulation command from the menu, and then pick up several tool tracks in the work area or the processing management window area, and click the right mouse button to confirm to call into the track simulator. First pick up a number of tracks in the work area or the processing window area, then right-click in the processing management window area to pop up the right-click menu, and then click the track simulation option to load the track simulator.
