Automatic Slant Bed CNC Lathe with Turret
Automatic Slant Bed CNC Lathe with Gantry Loader and Turret
The Automatic Slant Bed CNC Lathe with Gantry Loader with Turret for metal working.
Gantry loader popular as loader construction allows easy and quick palletising and arrangement of workpiece and workpiece pick-up at correct position.
IHT series Tuning machine with FANUC control system, Included Standard Equipment and Standard Control System Functions. Integrally molded low center of gravity casting bed, 30/45 ° saddle through optimized design, It has a large shock damping and a smaller amount of deformation, the main axle box, turret. Providing high-rigidity structure basis. 30/45 ° slant bed design to facilitate the operator upper and lower parts, but also to ensure. Smooth chip evacuation.
Compact design with HT300 high tension Meehanite cast-iron machine bed.
Perfect accessibility and optimal working depth.
The ideal machine for training, with minimal space requirement and uitable working depth to the spindle.
Increased productivity with up to 12 driven tools ( optional).
Most updated control technology: FANUC Oi-TF with10 4"panel (optional or SIEMENS 828D (840D optional).
Spindle bearing lubricant:grease.
medium size lathe for cut steel pipe thread
1.Super Rigidity
The machine structure is integrated into a strong base,lower barycenter, 30°/45° saddle desigh to achieve better vibration damping and reduce deformation, providing headstock & turret with a very stable base.30°/45° slant bed structure, more convenient for bar loading& unloading, smoother for chip removal.
2.Modern Popular Control Packages
iHT series have optional FAUNC 0iTF control package &Siemens 828D control package, 8.4' display, 10.4' display,extra interfaces etc. ready for customers.
3.Super Cost Performance
German lineage iHT Series boast best components, such as SAUTER turret, NSK bearings etc. to gurantee the high precision performance. Meanwhile we offer competitive price to make iHT series super high cost performance.
4.User-friendly Design
Minimal space occupation but mostly compliant to the actual work area, full protective enclosure with human aesthetic design, stainless telescopes cover, provide safe & clean working environment and better durability.
5.Abundant Options
Electric turret, servo turret, powered turret, upgrade spindle power, upgrade spindle torque, upgrade bore of cylinder & chuck, drawer type coolant tank, tool probe, oil-mist seperator etc. options ready for customers.
6.High efficiency line operation (optional)
Thanks to the advanced truss transmission device. it is possible to combine multiple machines with a single task, greatly reducing the transmission time between each process and increasing effIciency.
